제품소개
Coater
특징
1. W/Ti/Ni/Cr등의 성막에 대응
2. Magnetron Head 채용
3. Micro Computer 탑재로 성막을 고정밀도로 Control 가능
4. Full Auto/Manual Mode
|
SPEC |
|
|
Target size & Sample Base |
Φ49mm / Φ70mm |
|
Operation of evacuation |
Automatic |
|
Sputtering System | DC Magnetron Sputtering |
|
High Voltage Power Supply |
0~5mA/0~3kV(system control) |
|
Gas regulating mechanism |
Needle valve(system control) |
|
Chamber Size |
160(Φ) X 160(D)mm (SUS) |
|
Dimensions and Weight |
Main unit : 360(W) X 422(D) X 265(H)mm, 20kg RP : 460.5(W) X 173.5(D) X 264(H)mm, 22.4kg |
Power Supply | Single Phase AC 100V 50/60Hz 10A |
